Alfa Laval’s range of equipment and proven expertise help optimise key processes in coal beneficiation and add further security to the storage of mine waste. With our solid-bowl decanter centrifuges installed, you can look forward to recovering and re-using large quantities of process water, which will help cut lifecycle cost, minimise environmental impact, save space and boost capacity as well.
Robust technology for coal tailings dewatering
- Excellent output (solids dryness) even in tough conditions
- Removes need for tailings dams
- Reduces footprint as well as capital and maintenance costs
- Contained process resulting in good and safe working conditions
- Full support from our global sales & service team, even in remote locations
Our solid-liquid separation solutions are an effective, proven, high capacity solution for dewatering coal tailings and mine wastewater. They are also an effective solution for fine coal recovery from flotation concentrate as well as from lean streams. The dewatering technology produces a cake with up to 70% dry solids by mass, which can then be used for co-disposal with coarse rejects.
Tackling tailings safely and sustainably
Alfa Laval decanter centrifuges are a proven, efficient solution for large-scale dewatering of tailings and removing the finest particles that conventional solids control equipment is unable to deal with. They offer a cost effective, sustainable and, above all, safe solution to manage tailings, acting as a complement to traditional separation systems such as thickeners, sedimentation basins and filters or replacing old systems altogether.
How it works
Alfa Laval’s solid bowl decanter centrifuges have been specifically developed for large scale, heavy duty solid-liquid separation tasks in the mining and mineral industry.
A Solid Bowl Centrifuge (SBC) consists of a horizontal bowl with a scroll conveyor inside it which is together referred to as the rotating assembly. The assembly spins around its own axis at high speed, thereby generating high centrifugal force that enables separation of tailings solids from the liquid. The separated solids are scrolled out by the conveyor in the form of a dry solids cake whereas the clear liquid (centrate) overflows the weir plates located at the opposite end. Watch the animation to see how it works.
Contact Alfa Laval Australia today to get a quote or find out more about our solid bowl centrifuge trial unit.
Local support for your solid bowl decanter centrifuge
No site is too remote. Our team of experienced service engineers based at our Huntingwood/Sydney Service Centre and around Australia help you ensure that your solid bowl decanter centrifuge is performing at its best, so you can focus on the rest. Alfa Laval Australia is at your service.
How the technology works
Alfa Laval P2 and P3 decanter centrifuges are specifically designed to separate mineral ore slurries as well as tailings into solid phase and liquid phase. Separation takes place in a horizontal cylindrical bowl equipped with a screw conveyor. The feed slurry enters into the bowl through a stationary inlet tube and is then smoothly accelerated in the feed zone. Centrifugal forces of up to 3,500 G separate the solid particles from the liquid and the solids accumulate on the inner surface of the bowl.
The conveyor rotates in the same direction as the bowl, but at a different speed. This gives an axial thrust to the solid particles and the conveyor conveys those particles towards the conical end of the bowl. The solids leave the bowl through the solids discharge openings into the casing whereas the clarified liquid leaves the bowl by flowing over adjustable plate dams or power tubes into the casing.
Opportunities throughout your process
Explore the mining flowchart and discover how an Alfa Laval decanter centrifuge can help streamline your operations in various process areas.
Tailing dewatering - Breaking new ground in mining and minerals
Alfa Laval decanters revolutionize coal mine tailings management strategy.
The Rix’s Creek coal mining operation, part of the Bloomfield Group, set out to improve its onsite coal tailings management as part of its sustainability strategy to reduce water and energy consumption and minimize the surface footprint of waste handling processes.
After evaluating various technologies, Rix’s Creek engineers installed an Alfa Laval decanter centrifuge to dry coal tailings.
The result? Savings in capital expenditures as well as, about 90% recovery and re-use of the process water.
Read more about the efficiency, practicality and technical details of the Alfa Laval range of solid-bowl decanter centrifuges for the coal mining industry by downloading the brochure.
Meet the tailings dewatering challenge with Alfa Laval’s decanter centrifuges. They offer a cost effective, sustainable and, above all, safe solution to manage tailings. Download the brochure to read more about our cleaner, more efficient and safer solid-liquid separation systems.
Make sustainable development happen!
If you are looking for ways to increase the efficiency of your coal tailings management and make a meaningful contribution to the global sustainable development goals, contact Alfa Laval today to learn more about our proven and cost efficient solutions.
